Concept: Torque motors are offered for various applications where the rpm of motor is required to be changed with constant torque.

Voltage: 215 volts +- 5% 50 Hz. +- 3% for single phases (on customer request we are also able to supply motor in 110 volts on 60 Hz), 415 volts +- 5% 50 Hz. +- 3% for three phases (on customer request we are also able supply motor in 220, 380, 460, 525 volts on HZ. 50 or 60 Hz ).

Insulation: Insulation class F with constant duty (s1).

Range: Torque motors available are three phases and single phase.

Torque motor available 0.12 to 10 H.p. Frame 63 to 160L In Three phase and in single phase up to 0.12 to 1.0 H.p.
Motor providing in 4, 6 & 8 pole.

Mounting: Foot – Flange – Face ( B3 / B5 / B14 )
